About Your System 55
• Mezzanine card 3, connection 1 connects to I/O module C1, port n+8 .
Mezzanine card 3, connection 2 connects to I/O module C2 port
n+8.
• Mezzanine card 4, connection 1 connects to I/O module B1, port n+8 .
Mezzanine card 4, connection 2 connects to I/O module B2 port
n+8.
For example, in a full-height blade mezzanine card 3, connection 1 connects
to I/O module C1, port
13 and Mezzanine card 3, connection 2 connects to I/O
module C2 port
13 . Table 1-14 shows the port number assignments for the
eight possible full height blade locations.
NOTE: Even though M610x is a full blade system, only two mezzanine card slots
(MEZZ1_Fab_C1 and MEZZ2_FAB_B1) in the expansion bay are available for use.
The other two slots on the system board (MEZZ1_FAB_C and MEZZ2_FAB_B) are
occupied by the mezzanine interface card which provides connectivity between the
PCIe expansion-card riser and the system board.
For an M610x blade in bay n:
• Mezzanine card B (in the expansion bay) connects to I/O module B1, port
n+8 and I/O module B2, port n+8.
• Mezzanine card C (in the expansion bay) connects to I/O module C1, port
n+8 and I/O module C2, port n+8.
Table 1-13. Example of I/O Module Port Assignments - M610x Blade in slot 2
Blade 2 I/O Module
A1 B1 C1 C2 B2 A2
Mezzanine
Card C
Port 10 Port 10
Mezzanine
Card B
Port 10 Port 10
