About Your System 63
Dual-Port Mezzanine Cards
For a half-height blade in bay n:
• The integrated NIC connects to I/O module A1, port
n
and I/O module
A2, port
n.
• Mezzanine card B connects to I/O module B1, port
n
and I/O module B2,
port
n.
• Mezzanine card C connects to I/O module C1, port
n
and I/O module C2,
port
n.
For example, in a blade in slot 12, the integrated NIC
connects
to
I/O module
A1, port
12 and I/O module A2, port 12.
Figure 1-23 shows the port connections for a half-height blade in bay 1 with
two mezzanine cards.
Table 1-17. Example of I/O Module Port Assignments - Half-Height Blade 1
Blade 1 I/O Module
A1 B1 C1 C2 B2 A2
Integrated NIC Port 1 Port 1
Mezzanine
Card C
Port 1 Port 1
Mezzanine
Card B
Port 1 Port 1
