About Your System 71
Figure 1-27. Cisco Ethernet Switch Module Features
1 Stackwise Plus connectors (not
enabled in CBS 3032)
2 10/100/1000 Mb Ethernet
connectors (4)
3 option bays (2) 4 Cisco status indicators
5 mode button 6 console port for switch
management
7 power indicator 8 status/identification indicator
