About Your System 75

Figure 1-29. PowerConnect M8024 Switch Module

1 optional module with four SFP+

ports

2 optional module with three CX4

ports

3 serial connector for optional USB

type-A form-factor cable

4 power indicator

5 status/identification indicator
