NOTE: Connectors on the Ethernet pass-through module correspond directly to the
blade number. For example, blade 5 is connected to port 5 on the Ethernet pass-
through module. Integrated network adapter 1 maps to I/O slot A1. Integrated
network adapter 2 maps to I/O slot A2.
1 link indicator (16) 2 activity indicator (16)
3 RJ45 Ethernet connector (16) 4 power indicator
5 status/identification indicator
Table 1-24. Ethernet Pass-through Module Indicators
Indicator Type Pattern Description
Link
indicator/activity
indicator
Green on,
amber
blinking
The Ethernet connector is linked to the blade and
there is network activity.
Green on,
amber off
The Ethernet connector is linked to the blade and
there is no network activity.
Green off,
amber
blinking
The Ethernet connector is not linked to the blade
and there is network activity.
Green
off/amber off
The Ethernet connector is not linked to the blade
and there is no network activity.
Power indicator Off Power to the module is off.
Green Module has power.
Status/
identification
indicator
Blue on Active module.
Amber
flashing
Fault condition in module.
NOTE: Ethernet media speed is configured through the blade LOM firmware or by the
operating system. Speed and duplex settings are not configured through the pass-
through module itself.
