Component Secured to Screw type Quantity Screw image
Rear-I/O cover Computer base M2.5x7 2
Solid-state
drive
Computer base M2x3 1
Subwoofer Palm-rest
assembly
M2x2 2
System-board
assembly
Palm-rest
assembly
M2.5x5 7
Touchpad
bracket
Palm-rest
assembly
M2x3 5
Tron-light
holder
Palm-rest
assembly
M2.5x5 2
Wireless-card
bracket
Computer base M2x3 1
