Dell Alienware 17 R5 User Manual

Removing the battery
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your computer.
For more safety best practices, see the Regulatory Compliance home
page at
www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Follow the procedure from step 1 to step 4 in “Removing the hard drive”.
3 Remove the wireless card.
4 Remove the solid-state drive.
5 Remove the rear-I/O cover.
6 Remove the computer base.
Procedure
1 Remove the four screws (M2.5x5) that secure the battery to the palm-rest
assembly.
99

Dell Alienware 17 R5 Specifications

General

Weight	4.42 kg (9.74 lbs)
Wireless	Killer 1550 802.11ac 2x2 WiFi and Bluetooth 5.0
Processor	Intel Core i7-8750H or i9-8950HK
Graphics	NVIDIA GeForce GTX 1080
Display	17.3 inch FHD (1920 x 1080) 60Hz Anti-Glare IPS
RAM	Up to 32GB DDR4
Storage	1TB HDD
Operating System	Windows 10 Home
Battery	99 Whr Lithium Ion
Ports	1x Thunderbolt 3, 3x USB 3.0, 1x HDMI 2.0, 1x Mini-Display Port, 1x Alienware Graphics Amplifier Port, 1x RJ-45 Ethernet
