Replacing the display assembly
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your computer.
For more safety best practices, see the Regulatory Compliance home
page at
www.dell.com/regulatory_compliance.
Procedure
1 Place the palm-rest assembly on the display assembly.
2 Push the antenna cables, the logo-board cable, the tobii eye-tracker cable,
and the display cable through the holes on the palm-rest assembly.
3 Route the tobii eye-tracker cable and the display cable through the routing
guides on the palm-rest assembly.
96
