Setting up the monitor
VESA wall mounting (optional)
Figure 34. VESA wall mounting
NOTE: Use M4 x 10 mm screws to connect the monitor to the wall-mounting kit.
Refer to the instructions that come with the VESA-compatible wall-mounting kit.
1. Place the display on a soft cloth or cushion at the edge of the desk.
2. Remove the stand. See Removing the monitor stand.
3. Use a Phillips crosshead screwdriver to remove the four screws securing the plastic cover.
4. Attach the mounting bracket from the wall-mounting kit to the monitor.
5. Mount the monitor on the wall. For more information, see the documentation that shipped with the wall-mounting kit.
NOTE: For use only with UL or CSA or GS-listed wall mount brackets with minimum weight or load-bearing capacity of 16.92
kg (AW2725DM)/26.32 kg (AW3225DM).
