About your monitor
Table 11. PBP preset display modes.
Display mode
Horizontal frequency
(kHz)
Vertical frequency
(Hz)
Pixel clock (MHz)
Sync polarity
(Horizontal/Vertical)
IBM 720 x 400 31.47 70.08 28.32 -/+
VESA 640 x 480 37.50 75.00 31.50 -/-
VESA 640 x 480 31.47 59.94 25.18 -/-
VESA 720x480 31.50 60.00 27.03 +/+
VESA 800 x 600 37.88 60.32 40.00 +/+
VESA 800 x 600 46.88 75.00 49.50 +/+
VESA 1024 x 768 48.36 60.00 65.00 -/-
VESA 1024 x 768 60.02 75.03 78.75 +/+
VESA 1152 x 864 67.50 75.00 108.00 +/+
VESA 1280 x 720 44.77 59.86 74.50 -/+
VESA 1280 x 800 49.31 59.91 71.00 +/+
VESA 1280 x 960 60.00 60.00 108.00 +/+
VESA 1280 x 1024 63.98 60.02 108.00 +/+
VESA 1280 x1024 79.98 75.02 135.00 +/+
VESA 1440 x 900 55.94 59.89 106.50 -/+
VESA 1680 x 1050 65.29 59.95 146.25 -/+
VESA 1720x1440 88.82 59.97 167.00 +/-
VESA 1920 x 1080 67.50 60.00 148.50 +/+
VESA 880x1440 88.70 59.98 92.25 +/-
VESA 2560x1440 88.79 59.97 241.5 +/-
VESA 1136x1440 88.82 59.92 115 +/-
VESA 2304x1440 88.82 59.94 218.75 +/-
Table 12. PIP/PBP mode.
Main Window
Sub-Window
HDMI 1 HDMI 2 DisplayPort
HDMI 1 - √ √
HDMI 2 √ - √
DisplayPort √ √ -
