Using AlienFX™ function
Display configuration
Click the Display button to adjust the display settings.
Table 27. Display configuration.
Feature Description
Brightness
Drag the sliders to make the adjustment. Refer to Brightness and Contrast.
NOTE: These features may be disabled depending on the current HDR state.
Contrast
Preset Modes
The Preset Modes dropdown list changes according to the state of Use HDR switch.
When you toggle the SMART HDR switch to the On state, see SMART HDR. When you toggle the
SMART HDR switch to the Off state, see Preset Modes.
Use HDR To play the HDR, toggle the SMART HDR switch to On or Off.
Resolution/Refresh Rate
Allows you to change the settings of resolution and refresh rate of the system.
NOTE: This feature is disabled when you set to duplicate screen on multiple monitors.
Input configuration
This feature allows you to display images from different video sources.
When you toggle the PIP/PBP switch to the ON state, the options of preset PBP or PIP modes are displayed under the preview
window, and you can select your preferred mode.
This feature brings up a window displaying the visual output from another input source.
Table 28. PIP/PBP configuration.
Feature Description
Current Input Source Select video inputs for your display screen.
PIP/PBP
• PIP/PBP Configuration: To play the PIP/PBP, toggle the switch to the On or Off state. When
switch to On, you can choose the PIP/PBP types at the left feature buttons, as following:
1. PIP/PBP Off
2. PIP/PBP Small
3. PIP/PBP Large
4. 50%-50%
5. 25%-75%
6. 75%-25%
7. 33%-67%
8. 67%-33%
• Input Source: Select video inputs for your Main window and Sub window.
• Video Swap: You can swap video inputs between the main window and sub window.
• Video Swap Hotkey: You can define the shortcut keys to swap video inputs between the main
window and sub window.
• Change PIP Position: You can define the shortcut keys to toggle the position of the PIP Sub
window.
• Contrast (Sub): Drag the slider to adjust the contrast level of the picture in the Sub window.
