Setting up the monitor
Using the tilt and height adjustment
NOTE: The following instructions are applicable only for attaching the stand that was shipped with your monitor. If you are
attaching a stand that you purchased from any other source, follow the setup instructions that were included with the stand.
Tilt adjustment
With the stand attached to the monitor, you can tilt the monitor for the most comfortable viewing angle.
-5
o
21
o
5
o
5
o
Figure 18. Tilt adjustment
Height adjustment
NOTE: The stand extends vertically up to 110 mm. The following image illustrates how to adjust the stand vertically.
110 mm
Figure 19. Height adjustment
