Setting up the monitor
6. Attach the stand assembly to the display.
• Fit the two tabs on the upper part of the stand to the groove on the back of the display.
• Press the stand down till it snaps into place.
Figure 15. Attach the stand assembly to the display
7.
Hold the stand riser and lift the monitor carefully, then place it on a flat surface.
CAUTION: Lift the monitor carefully to prevent it from slipping or falling.
Figure 16. Hold the stand riser and lift the monitor
8. Lift the protective cover from the monitor.
Figure 17. Lift the protective cover from the monitor
