CHAPTER 5: DRIVE(S)

1 Media Card Reader 2 FlexBay dock

3 screws (4)

Remove the four screws that secure the Media Card Reader to the FlexBay 7.

dock.

Slide the Media Card Reader out of the FlexBay dock.8.
