CHAPTER 16: RIGHT SIDE-PANEL(S)
Place the chassis in an upright position.8.
Slide and pull the right top-panel away from the chassis.9.
1
1 right top-panel
Disconnect the lighting-board cable from the connector on the master I/O 10.
board.
Remove the two screws that secure the lighting board to the chassis.11.
Lift the lighting board up and away from the chassis. 12.
1
2
1 lighting board 2 screws (2)
