CHAPTER 17: ACTIVE-VENTING ASSEMBLY

Remove the two screws that secure the top panel to the chassis.10.

Lift the top panel away from the chassis.11.

Remove the three screws that secure the active-venting assembly to the 12.

chassis.

Disconnect the cables that connect the active-venting assembly to the 13.

connectors on the master I/O board.

Lift the active-venting assembly away from the chassis.14.

1 screws (3) 2 active-venting assembly

3 top panel 4 top-panel screws (2)
