Brocade Adapters Installation and Reference Manual 137
53-1002144-01
Boot over SAN
4
Under the Ad No column, 1/0 and 1/1 are the first port and second port respectively on the
first installed adapter while 2/0 and 2/1 are the first and second port on the second installed
adapter.
A maximum of 8 ports can display on a screen, and a maximum of 16 ports are supported by
the BIOS Configuration Utility. Select Page Up to go to a previous screen or Page Down to go to
the next screen.
To bypass functions and stop loading BIOS, you must to press X for each port. Press X within 5
seconds to bypass execution of functions displayed on screens. If you press X after 5 seconds,
the next function (instead of current function) will be bypassed.
3. Select a port that you want to configure.
A screen similar to the following displays. (In the following example, port 0 on the Brocade
1020 CNA was selected.)
