Initial Settings Procedures Using Dell Printer Configuration Web Tool
19
Note • If [Use this certificate] is not available, then the selected certificate has expired, or is not
valid. All certificates in the certification path (chain of trust) must be installed on the
machine and be valid.
7
Click [Reboot Machine] if prompted.
Enabling S/MIME communication
1
Click [Security] on the [Properties] screen.
2
Click [SSL / TLS Settings].
3
Check the [Enabled] box for [S/MIME Communication].
4
Click [Apply].
5
Click [Reboot Machine] if prompted.
For more information on the S/MIME settings, refer to "15 Tools" > "Connectivity & Network
Setup" > "Security Settings" > "S/MIME Settings" in the User's Guide.
Set LDAP Server
Configure the LDAP server settings to use the Access Control feature.
1
Click [Connectivity] on the [Properties] screen.
2
Click [Protocols].
3
Click [LDAP].
4
Click [LDAP Server].
5
On the each menu, make the following settings:
• IP Address/Hostname
•Port number
•LDAP Server
• Search Directory Root
Note • Enter the distinguished name of the root node. (Example: CN=users, DC=mydomain,
DC=dell, DC=com)
• Login credentials to Search Entries
To Next Page
