Dell Chromebook 11 3380 User Manual

Installing the speakers
1 Place the speakers into the slots on the computer.
2 Route the speaker cable through the routing channel.
3 Ax the adhesive tape to secure the speaker cable to the computer.
4 Connect the speaker cable to the connector on the system board.
5 Install the:
a battery
b base cover
c microSD card
6 Follow the procedure in After working inside your computer.
Touchpad panel
Removing the touchpad
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a microSD card
b base cover
c battery
3 To remove touchpad cable:
a Lift the latch and disconnect the touchpad cable from the computer [1].
b Lift the touchpad cable o from the system board [2].
16
Removing and installing components

Dell Chromebook 11 3380 Specifications

General

Operating System	Chrome OS
Battery Life	Up to 10 hours
Display	11.6 inch HD (1366x768)
RAM	4GB
Ports	1 x HDMI, 1 x Headphone/Microphone combo jack
Wireless	802.11ac Wi-Fi, Bluetooth
Battery	3-cell 42 WHr
