Dell DCS-1130 Setup and Features Information
NIC Indicator Codes | Page 9
Figure 5. NIC Indicators (KVM over IP Port)
1
2
1. link indicator 2. activity indicator
NIC Status Indicator (link) Condition
Steady green Link at 100 Mbps speed
O Link at 10 Mbps speed
NIC Status Indicator (activity) Condition
Steady green Link LAN / No access
Blinks green LAN access
Green o Idle
