116 Removing and Installing Parts
9
Connect the USB cable to the back of the Media Card Reader and to the USB connector on the system
board (see "System Board Components" on page 81).
10
Route the USB cable through the cable routing clip.
11
Replace the computer cover (see "Replacing the Computer Cover" on page 121).
12
Power up the system and enter system setup (see "System Setup" on page 127). Set the
USB for
FlexBay
value to
ON
.
CD/DVD Drive
CAUTION: Before you perform any of the procedures in this section, follow the safety instructions in the Product
Information Guide.
CAUTION: To guard against electrical shock, always unplug your computer from the electrical outlet before
opening the cover.
1 Media Card Reader (optional) 2 USB cable
2
1
