Dell Dimension 9200 - Removing a CD;DVD Drive

Removing and Installing Parts 117
Removing a CD/DVD Drive
1 Follow the procedures in "Before You Begin" on page 77.
2 Remove the computer cover (see "Removing the Computer Cover" on page 78).
3 Remove the drive panel (see "Removing the Drive Panel" on page 100).
4 Disconnect the power cable from the back of the drive and the CD/DVD drive cable from the back of
the drive and the system board.
1 CD/DVD drive cable 2 power cable 3 system board
2
1
3
