Setting Up and Using Your Computer 15
Back View of the Computer
1 power connector Insert the power cable.
2 back I/O connectors Plug USB, network, S/PDIF, and audio devices into the appropriate connectors
(see "Back Panel Connectors" on page 16).
3 card slots (6) Access connectors for any installed PCI or PCI Express cards.
4 power selection switch Manually select AC input power: 115 volts or 230 volts
2
1
3
4
