Removing and Installing Parts 119
5
Remove three shoulder screws from the inside of the drive-panel insert and attach the screws to the
new drive.
6
Slide the drive into the drive bay until the drive clicks into position.
7
Connect the power cable to the drive and the CD/DVD cable to the drive and system board.
1 CD/DVD drive 2 shoulder screws (3)
1 CD/DVD cable 2 power cable 3 system board
2
2
1
3
