Appendix 81
Ports and Connectors (continued)
Internally accessible:
Primary IDE channel
40-pin connector on PCI local bus
Secondary IDE channel
40-pin connector on PCI local bus
Floppy drive
34-pin connector
Serial ATA
two 7-pin connectors
Video
Type Integrated Intel Extreme Graphics controller
Audio
Audio controller ADI 1980
Network
Network controller Integrated Intel
®
PRO 10/100 Ethernet
Controls and Lights
Power control push button
Front-panel power light solid green for power-on state; blinking green for standby state
Hard-drive access light green
Diagnostic code lights four bicolor (amber and green) located on back panel
Power
DC power supply:
Wattage
250 W
Heat dissipation
853 BTU (fully-loaded computer without monitor)
Voltage
(see the safety instruction located in
the
Product Information Guide
for
important voltage setting
information)
100 to 120 V at 60 Hz; 200 to 240 V at 50 Hz
Backup battery 3-V CR2032 coin cell
Physical
Height x Width x Depth 36.8 x 18.4 x 42.6 cm
(14.5 x 7.25 x 16.75 inches)
Weight 10.4 kg (23 lb)
