Dell E178FPC Service Manual

17" LCD Color Monitor Dell E178FPC
28
3. Turn over the monitor as the Fig,
hold the rear cover, and then
slightly remove it.
Remove the bezel:
Remove the small shield as the
arrowhead direction, disconnects
the keyboard connector, and then
remove the bezel.
Remove the shield :
1. Remove the screw by Torque B
or by manual and remove the small
shield
