17" LCD Color Monitor Dell E178FPC
9
3
Auto Adjust
Use this button to activate automatic setup and adjustment. The
following dialog will appear on screen as the monitor self-adjusts to the
current input:
Auto Adjust In Progress
Auto Adjustment button allows the monitor to self-adjust to the
incoming video signal. After using 'Auto Adjustment', you can further
tune your monitor by using the 'Pixel Clock' and 'Phase' controls in the
OSD.
NOTE: Auto Adjust will not occur if you press the button while there are
no active video input signals, or attached cables.
4
Power Button and Indicator
The green LED indicates the monitor is on and fully functional. An
amber LED indicates DPMS power save mode.
The Power button turns the monitor on and off.
On Screen Menu/Display (OSD)
Direct-Access Functions
Function Adjustment Method
Auto adjustment
Use this button to activate automatic setup and adjustment. The following
dialog will appear on screen as the monitor self-adjusts to the current input:
Auto Adjust In Progress
Auto Adjustment button allows the monitor to self-adjust to the incoming
video signal. After using 'Auto Adjustment', you can further tune your monitor
by using the 'Pixel Clock' and 'Phase' controls in the OSD.
NOTE: Auto Adjust will not occur if you press the button while there are no
active video input signals, or attached cables.
Brightness / Contrast
With the menu off, press
button to display the 'Brightness' and 'Contrast'
adjustment menu.
The 'Brightness' function adjusts the luminance of the flat panel.
Adjust 'Brightness' first, and then adjust 'Contrast' only if further adjustment is
