Dell E178FPC Service Manual

17" LCD Color Monitor Dell E178FPC
76
CN804 033G8021 2E F WAFER
051G 6 4503 GLUE_RTV
IC903 056G 139 3A IC PC123Y22FZ0F
NR901 061G 58080 WT 8 OHM NCT
R908 061G152M104 64 100KOHM 5% 2W
C904 063G 10722410M 0.22 UF 275VAC
C903 063G107K474 6S CAP X2 0.47UF K 275VAC
C811 065G 6J1006ET 10PF 5% SL 6KV
C801 065G 6J1006ET 10PF 5% SL 6KV
C902 065G305M1022BP Y2 1000PF M 250VAC Y5P
C901 065G305M1022BP Y2 1000PF M 250VAC Y5P
C921 065G306M4722BP 4700PF +-20% 400VAC
C905 067G 40Z10115K
CAP 105℃ 100UF M 450V
C939 067G215P1024PV
CAP 105℃ 1000UF M 25V
C915 067G215P4713AV
CAP 105℃ 470UF M 16V
C803 067G215P4714AV
CAP 105℃ 470UF M 25V
C802 067G215P4714AV
CAP 105℃ 470UF M 25V
C917 067G215P6814PV CAP 105C 680UF M 25V
C918 067G215P6814PV CAP 105C 680UF M 25V
L903 073G 253191 S IND CHOKE 1.1uH
L904 073G 253191 S IND CHOKE 1.1uH
L902 073L 174 26S2G LINE FILTER 27mH
T801 080GL19T 24 YS X'FMR 740mH YS04170157
T802 080GL19T 24 YS X'FMR 740mH YS04170157
T901 080GL19T501 N XFMR POWER 650uH+-5% YUVA
CN901 087G 501 32 S AC SOCKET
BD901 093G 50460 28 BRIDGE DIODE KBP208G LITEON
D907 093G3006 1 1 31DQ06FC3 NIHON INTER
CN902 095G 82510X511 HARNESS 10P-9P 210MM
705GQ757018 Q901 ASS'Y
051G 200 1 OIL FOR DISAPPEAR
Q901 057G 667 21 STP10NK70ZFP
AM1G1730 8120 GP SCREW
Q90G6263 3 HEAT SINK
705GQ893008 D906 ASS'Y
051G 200 1 OIL FOR DISAPPEAR
D906 093G 60245 SP10150 10A 150V ITO-220 BY SECOS
AM1G1730 8120 GP SCREW
Q90G0117 2 HEAT SINK
IC801 056G 379 22 IC TL494IDR SOIC-16

Dell E178FPC Specifications

General

Brand	Dell
Model	E178FPC
Category	Monitor
Language	English
