2. Push the - and + buttons to move between the setting options. As you move from one icon to another, the option name is highlighted. See the table
below for a complete list of all the options available for the monitor.
3. PushtheMENUbuttononcetoactivatethehighlightedoption.
4. Push - and + button to select the desired parameter.
5. Push MENU to enter the slide bar and then use the - and + buttons, according to the indicators on the menu, to make your changes.
6. Push the MENU button once to return to the main menu to select another option or push the MENU button two or three times to exit from the OSD
menu.
Main Menu for Analog (VGA) Input
Main Menu for Digital (DVI) Input
NOTE: Auto Adjust is only available when you are using the analog (VGA) connector.
Select to exit the main menu.
Use this menu to activate Brightness/Contrast adjustment.
Brightnessadjuststheluminanceofthebacklight.
Push the + button to increase luminance and push the - button to decrease luminance (min 0 ~ max 100).
Adjust Brightness first, and then adjust Contrast only if further adjustment is necessary.
Push the + button to increase contrast and push the - button to decrease contrast (min 0 ~ max 100).
The Contrast function adjusts the degree of difference between darkness and lightness on the monitor screen.
Even though your computer recognizes your monitor on startup, the Auto Adjustment function optimizes the display settings for use with
your particular setup.
Select to activate automatic setup and adjustment. The following dialog appears on a black screen as the monitor self-
