Dell E248WFP - Back View; Side View

Back View

BackviewBackViewwithmonitorstand

Side View

3
Brightness & Contrast / Down(-) button
4
Auto-Adjust / Up(+) button
5
Power on/off button with LED indicator
Label
Description/Use
1
DellSoundbarmountingbrackets
Attach the optional Dell Soundbar.

2
Securitylockslot
Attach a lock to secure your monitor.
3
Stand removal button
Press to release the stand.
4
VESA mounting holes (100mm - behind
attached stand)
Use to mount monitor.
5
Barcode serial number label
Refer to this label if you need to contact Dell for
technical support.
6
Regulatoryratinglabel
Listtheregulatoryapprovals.
7
Cable management opening
Help organize cables by passing them through the
holder.
Rightside
Left side
