Dell E248WFP - Removing the Stand

1. Workingfromtherearofthemonitor,attachSoundbarbyaligningthetwoslotswiththetwotabsalongthebottomrearofthemonitor.
2. SlidetheSoundbartotheleftuntilitsnapsintotheplace.
3. Connect the Soundbar with the power brick.
4. Plugthepowercablesofthepowerbrickintoanearbyoutlet.
5. Insert the lime green mini stereo plug from the rear of the Soundbar into the computer's audio output jack.
Removing the Stand

After placing the monitor panel on a soft cloth or cushion, press and hold the LCD removal button, and then remove the stand.

Back to Contents Page

NOTICE: Do not use with any device other than Dell Soundbar
NOTE: Soundbar Power Connector +12V DC output is for optional only.
NOTE: TopreventscratchesontheLCDscreenwhileremovingthestand,ensurethatthemonitorisplacedonacleansurface.
