Dell E248WFP - Plug and Play Capability; Flat Panel Specifications; Video Supported Modes; Preset Display Modes

Plug and Play Capability
You can install the monitor in any Plug and Play-compatible system. The monitor automatically provides the computer system with its Extended Display
Identification Data (EDID) using Display Data Channel (DDC) protocols so the system can configure itself and optimize the monitor settings. If required, the
user can select different settings, but in most cases monitor installation is automatic.
12
Floating
13
Floating
14
+5V / +3.3V power
15
Selftest
16
Hot Plug Detect
17
TMDS RX0-
18
TMDS RX0+
19
TMDS Ground
20
Floating
21
Floating
22
TMDS Ground
23
TMDS Clock+
24
TMDS Clock-
Flat Panel Specifications

Screen type
Active matrix - TFT LCD
Screen dimensions
24 inches (24-inch diagonal viewable image size)
Preset display area:

Horizontal
520 mm (20.4 inches)
Vertical
325.6 mm (12.8 inches)
Pixel pitch
0.27 mm
Viewing angle
160°(Vertical)typical,160°(Horizontal)typical
Luminance output
400 cd/m ²(typ)
Contrast ratio
1000:1 (typ)
Faceplate coating
Antiglare with hard-coating 3H
Backlight
6 CCFLs U-type backlight. 92% wide color gamut
Response Time
5ms typical (Black to White)
Resolution

Horizontal scan range
30 kHz to 81 kHz (automatic)
Vertical scan range
56Hzto76Hz
Optimal preset resolution
1920 x 1200 at 60 Hz
Highest preset resolution
1920 x 1200 at 60 Hz
Video Supported Modes

Video display capabilities (DVI playback)
480i/ 480p/ 576i/ 576p/ 720p/ 1080i/ 1080p
Preset Display Modes
