4. Locate the required WWAN connection.
5. Right-click the WWAN connection, and then select Connect or Disconnect to connect to or disconnect from the WWAN
adapter, respectively.
Common port mappings on Embedded Box PC 5000 with Windows 7 Professional for Embedded Systems
Serial port mapping
The following table shows the serial port mapping at the bottom of the Embedded Box PC 3000 with Windows 7 Professional for
Embedded Systems OS image.
Table 2. Serial port mapping
Number Port Type Connector Device Node
1 RS232/485 DB9 COM1
2 Multi-function port
(RS232/422)
7-in-1 cable COM2
3 RS232/485 DB9 COM3
Windows Embedded Standard 7 P/E
Overview
The Embedded Box PC is shipped with Windows Embedded Standard 7 P/E. For more information on Windows 7 operating system,
seehttps://support.microsoft.com/en-us.
Boot up and login
Before configuring the Windows Embedded Standard 7 P/E, connect a keyboard, mouse, and monitor to the Embedded Box PC.
1. Turn on the Embedded Box PC and login to Windows Embedded Standard 7 P/E.
2. Select regional settings.
3. Create a User Account.
4. Read and accept the EULA.
5. Select your preferred settings.
NOTE: Connect to a wireless network if available.
Windows Embedded Standard 7 P/E. basic functions
BIOS update
Download the latest BIOS version from www.dell.com/support. Run the executable in the download package from the local
machine.
Watchdog timer
The watchdog timer for Windows Embedded Standard 7 P/E. is enabled and disabled through the BIOS.
TPM support
Windows Embedded Standard 7 P/E. supports TPM 1.2. For more information, see Https://technet.microsoft.com/en-us/library/
cc749022.aspx.
System shutdown
Click the Start icon, then click Shut down to shut down the Embedded Box PC.
System restart
Click the Start icon, then click right-arrow next to the Shut down button and click Restart.
