TPM support
Windows 10 IoT Enterprise LTSB 2015 supports TPM 2.0. For more information, see Https://technet.microsoft.com/en-us/library/
cc749022.aspx.
System shutdown
Click the start icon then the power icon. Click Shut down to shut down the Embedded Box PC.
System restart
Click the start icon then the power icon. Click Restart to restart the Embedded Box PC.
LAN network
Click the Start icon then the settings icon. Click Network & Internet to configure the LAN on the Embedded Box PC.
Configuring WLAN network
Click the Start icon then the settings icon. Click Devices and the Bluetooth to configure the wireless devices on the Embedded Box
PC.
Configuring WWAN (DW5580) network
NOTE: For instruction on installing the WWAN card and SIM card, see the
Service manual
for your system at
www.dell.com/support. After installing the WWAN module and SIM card:
1. Click the Start icon then the settings icon.
2. Click Network & Internet.
3. Locate the WWAN connection in the Wi-Fi section and connect (or disconnect) the WWAN module.
Common port mappings
Serial port mapping
The table lists the serial port mapping on the Embedded Box PC 3000 and the multifunction port cable, with the Dell factory
installed Windows 10 IoT Enterprise LTSB 2015 OS.
Table 5. Serial port mapping
Serial port number Port type Connector Device Node
1 RS232/485 DB9 COM1
2 RS232/422—multi-function
port cable
7-in-1 cable COM2
3 RS232/485 DB9 COM3
Recommended drivers and applications for Embedded Box PC running Windows operating
system
NOTE: For more information about installing and configuring the Windows operating systems, see msdn.microsoft.com.
Dell recommends installing the drivers and applications required for the Embedded Box PC from www.dell.com/support in the
following sequence:
1. Intel Mobile Chipset Software Installation Utility
2. Critical Microsoft Quick Fix Engineering (QFE)
3. Graphics
4. Intel Management Technology
5. Audio
6. Integrated wired network adapter
25
