Configuring LAN/WLAN network
1. Click the Start icon then search for Network.
2. Open Network and Sharing Center.
3. Click Change adapter settings on the left panel.
to configure the LAN on the Embedded Box PC.
Configuring Bluetooth
1. Click the Start icon then search for Bluetooth.
2. Click Change Bluetooth settings .
Configuring WWAN (DW5580) network
NOTE: For instruction on installing the WWAN card and SIM card, see the
Service manual
for your system at
www.dell.com/support. After installing the WWAN module and SIM card:
1. Click the Start icon then search for Network.
2. Open Network and Sharing Center.
3. Click Change adapter settings on the left panel.
4. Locate the WWAN connection and select the entry to connect (or disconnect) to the WWAN module.
Common port mappings
Serial port mapping
The table lists the serial port mapping on the Embedded Box PC 3000 and the multifunction port cable, with the Dell factory
installed Windows Embedded Standard 7 P/E OS.
Table 3. Serial port mapping
Serial port number Port type Connector Device Node
1 RS232/485 DB9 COM1
2 RS232/422—multi-function
port cable
7-in-1 cable COM2
3 RS232/485 DB9 COM3
Windows 10 Professional
Overview
The Embedded Box PC is shipped with Windows 10 Pro. For more information on Windows 10 operating system, see https://
support.microsoft.com/en-us.
Boot up and login
Before configuring the Windows 10 Pro, connect a keyboard, mouse, and monitor to the Embedded Box PC.
1. Turn on the Embedded Box PC and login to Windows Pro.
2. Select regional settings.
3. Read and accept the EULA.
4. Create a User Account.
5. Select your preferred settings.
NOTE: Connect to a wireless network if available.
22
