Figure 38. Installing a drive into the drive carrier
Next steps
1. Install the drive carrier.
2. If removed, install the front bezel.
Drive backplane
Drive backplane
Depending on your system configuration, the drive backplanes supported are listed here:
Table 13. Supported backplane options
System Supported hard drives options
PowerEdge R6525
3.5-inch (x4) SAS, SATA backplane
2.5-inch (x8) SAS or SATA backplane
2.5-inch (x10) SAS, SATA or NVMe backplane
2.5-inch (x2) SAS/SATA/NVME rear backplane
