Table 4. QSFP28 port LEDs
LED Description
Link/Activity LED—100G, 40G, or 10G
● Off—No link
● Solid green—Link operating at maximum speed, 100G for
QSFP28 port
● Flashing green—Port activity operating at maximum
speed, 100G for QSFP28 ports
● Solid yellow—Port activity operating at a lower speed,
40G or 10G port
● Flashing yellow, 1 second on/off—Port beacon
Link/Activity LED—4x25G mode or 4x10G mode
● Off—No link
● Solid green—Link operating at maximum speed, 4x25G
port
● Flashing green—Link activity operating at maximum speed,
4x25G port
● Solid yellow—Link operating at a lowr speed, 4x10G port
● Flashing yellow, 1 second on/off—Port beacon
Link/Activity LED—2x50G mode
● Off—No link
● Solid yellow—Link operating at a lower speed, 2x50G port
● Flashing yellow—Port activity at a lower speed, 2x50G
port
● Flashing yellow, 1 second on/off—Port beacon
Prerequisites
The following is a list of components required for successful switch installation:
NOTE: For detailed installation instructions, see Site Preparations and S5148F-ON Installation.
● S5148F-ON switch or multiple switches, if stacking
● AC or DC country- and regional-specific cables to connect the AC or DC power source to each of the switches’ AC or DC
power supplies
● ReadyRail mounting brackets for rack installation, included
● Screws for rack installation
● #1 and #2 Phillips screw drivers, not included
● Torx screwdriver, not included
● Ground cable screws for L-bracket, included
● Copper/fiber cables
Other optional components are:
●
M3 or M4 ground cable screw, depending on your switch
● Extra mounting brackets
● Extra power supply unit
● Extra fan module
S5148F-ON switch configurations
You can order the S5148F-ON switch in several different configurations:
● S5148F-ON AC or DC Normal Airflow: fifty-four 10/25/40/50/100GbE ports—48 SFP28 1/10/25GbE ports and 6 QSFP28
40/100GbE ports, 2 AC or DC power supplies, and 4 fan subsystems with airflow from the I/O side to the power supply side.
● S5148F-ON AC or DC Reverse Airflow: fifty-four 10/25/40/50/100GbE ports—48 SFP28 1/10/25GbE ports and 6 QSFP28
40/100GbE ports, 2 AC or DC power supplies, and 4 fan subsystems with airflow from the power supply side to the I/O side.
● Fan with airflow from the I/O side to the PSU side—normal airflow.
● Fan with airflow from the PSU side to the I/O side—reverse airflow.
S5148F-ON switch
11
