Dell Force10 S4820T System

10 Hardware Overview
Table 1-1. 10GBT Ethernet Port LEDs
Table 1-2. QSFP+ Port LEDs
Table 1-3. OOB Ethernet Port LEDs
Feature Detailed Description
Link LED
• Off – No Link
• Solid green –Link on 10Gbps speed
• Solid Amber –Link on 100M or 1Gbps speeds
Activity LED • Off – No Link
• Blinking green – Transmit/Receive is active
Feature Detailed Description
Link LED • Off – No Link
• Solid green –Link on 40Gbps speed
• Solid Amber –Link on other speeds
Activity LED • Off – No Link
• Blinking green – Transmit/Receive is active
Feature Detailed Description
Link LED
• Off – No Link
• Solid green –Link on 1Gbps speed
• Solid Amber –Link on 100M or 10M speeds
Activity LED • Off – No Link
• Blinking green – Transmit/Receive is active
