Steps
1 Using the alignment posts and rubber grommets, place the speakers in the slots on the palm-rest and keyboard assembly
NOTE
: If the rubber grommets are pushed out of the speakers when removing the speakers, push them back in place
before replacing the speakers.
2 Route the speaker cable through the routing guides on the palm-rest and keyboard assembly.
3 Connect the speaker cable to the system board.
Next step
1 Install the battery.
2 Install the base cover.
3 Follow the procedure in After working inside your computer.
Identifier GUID-F6A4309E-A10E-4E7F-903C-3FFAE07278CD
Status Released
WLAN card
Identifier GUID-D2FFFCCA-CA48-41C2-BE4D-4318BE3C1DAC
Status Released
Removing the WLAN card
Prerequisites
1 Follow the procedure in Before working inside your computer.
2 Remove the base cover.
3 Remove the battery.
36
Removing and installing components
