Dell G3 3590 - System Board and Heat Sink Replacement

Identifier GUID-46B53388-5C4F-4861-92E0-6AE357EE9CBF
Status Released
System board
Identifier GUID-204C5111-9521-4463-8902-2C2D224FD498
Status Released
Removing the system board
Prerequisites
1 Follow the procedure in Before working inside your computer.
2 Remove the base cover.
3 Remove the battery.
4 Remove the solid-state drive/Intel Optane memory module.
5 Remove the WLAN card.
6 Remove the left fan.
7 Remove the right fan.
8 Remove the heat sink.
9 Remove the display assembly.
10 Remove the power-adapter port.
About this task
The following image indicates the location of the system board and provides a visual representation of the removal procedure.
NOTE
:
The I/O board connector is located underneath the system board. Turn the system board over and disconnect the I/O board cable
from the system board.
46 Removing and installing components
