Dell Latitude 3180 User Manual

System logs screen options
Option Description
BIOS Events Allows you to view and clear the System Setup (BIOS) POST events.
Thermal Events Allows you to view and clear the System Setup (Thermal) events.
Power Events Allows you to view and clear the System Setup (Power) events.
SupportAssist system resolution
Option Description
Auto OS Recovery
Threshold
The Auto OS Recovery Threshold setup option controls the automatic boot ow for SupportAssist System
Resolution Console and for Dell OS Recovery Tool.
• OFF
• 1
• 2 (default)
• 3
Updating the BIOS in Windows
It is recommended to update your BIOS (System Setup), on replacing the system board or if an update is available. For laptops, ensure that
your computer battery is fully charged and connected to a power outlet
NOTE
: If BitLocker is enabled, it must be suspended prior to updating the system BIOS, and then re-enabled after the BIOS
update is completed.
1 Restart the computer.
2 Go to Dell.com/support.
• Enter the Service Tag or Express Service Code and click Submit.
• ClickDetect Product and follow the instructions on screen,
3 If you are unable to detect or nd the Service Tag, click the Choose from all products.
4 Choose the Products category from the list.
NOTE
: Choose the appropriate category to reach the product page
5 Select your computer model and the Product Support page of your computer appears.
6 Click Get drivers and click Drivers and Downloads.
The Drivers and Downloads section opens.
7 Click Find it myself.
8 Click BIOS to view the BIOS versions.
9 Identify the latest BIOS le and click Download.
10 Select your preferred download method in the Please select your download method below window, click Download File.
The File Download window appears.
11 Click Save to save the le on your computer.
12 Click Run to install the updated BIOS settings on your computer.
Follow the instructions on the screen.
NOTE
: It is recommended not to update the BIOS version for more than 3 revisions. For example: If you want to update the BIOS
from 1.0 to 7.0, then install version 4.0 rst and then install version 7.0.
44 System setup options

Dell Latitude 3180 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Market positioning	Educational
Tjunction	105 °C
Processor cache	2 MB
Processor cores	4
System bus rate	- GT/s
Processor family	Intel® Pentium®
Processor series	Intel Pentium Processor N4000 Series for Mobile
Processor socket	BGA 1296
Processor codename	Apollo Lake
Processor frequency	1.1 GHz
Processor cache type	L2
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	2.5 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x2, 1x2+2x1
Thermal Design Power (TDP)	6 W
Scenario Design Power (SDP)	4 W
Maximum number of PCI Express lanes	6
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	On-board
Internal memory type	LPDDR3-SDRAM
AC adapter included	Yes
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
SSD form factor	M.2
Total storage capacity	128 GB
Compatible memory cards	SD
Number of SSDs installed	1
Display diagonal	11.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Number of execution units	18
On-board graphics card ID	0x5A84
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 505
Maximum on-board graphics card memory	8 GB
On-board graphics card base frequency	200 MHz
On-board graphics card burst frequency	750 MHz
Audio chip	Realtek ALC3246
Speaker power	2 W
Number of built-in speakers	2
Front camera resolution	1280 x 720 pixels
Front camera resolution (numeric)	1 MP
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
HDMI version	1.4
Docking connector	-
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Touchpad
Trial software	McAfee, Microsoft Office
Battery capacity	42 Wh
Number of battery cells	3
Cable lock slot type	Noble
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Processor ARK ID	95592
Processor package size	24 x 31 mm
Intel Identity Protection Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00
Sustainability certificates	ENERGY STAR
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V

Weight and Dimensions

Depth	206 mm
Width	303.3 mm
Height	20.75 mm
Weight	1260 g
