Installing The DC-In Port
Installing The DC-In Port
1. Replace the DC-In port to its original position in the computer.
2. Replace the DC-In bracket to its original position in the computer.
3. Tighten the screw to secure the DC-In bracket to the computer.
4. Install the system board
5. Install the display assembly.
6. Install the display hinge covers.
7. Install the palmrest assembly.
8. Install the media board
9. Install the Wireless Local Area Network (WLAN) card
10. Install the Wireless Wide Area Network (WWAN) card
11. Install the coin cell battery
12. Install the keyboard.
13. Install the keyboard trim.
14. Install the hard drive.
15. Install the ExpressCard.
16. Install the base cover.
17. Install the Subscriber Identity Module (SIM) Card
18. Install the optical drive.
19. Install the Secure Digital (SD) card.
20. Install the battery.
21. Follow the procedures in After Working Inside Your Computer.
