19
Media Board
Removing The Media Board
1. Follow the procedures in Before Working On Your Computer.
2. Remove the battery.
3. Remove the Secure Digital (SD) card.
4. Remove the optical drive.
5. Remove the base cover.
6. Remove the ExpressCard.
7. Remove the hard drive.
8. Remove the keyboard trim.
9. Remove the keyboard.
10. Remove the palmrest assembly.
11. Disconnect the media board cable from the system board.
12. Remove the screws that secures the media board to the computer.
