Dell Latitude E6510 - Page 47

Optical drives
DVD
DVD+/-RW
Blu-ray™
Display
Type and size
396.24 mm (15.6 inches) diagonal TFT with white LED
backlight
Active area (X/Y)
344.2 mm x 193.5 mm
(13.55 inches x 7.61 inches)
Dimensions
Height
210 mm (8.26 inches)
Width
360 mm (14.17 inches)
Diagonal
417 mm (16.14 inches)
Display Option 1: High Definition

Maximum resolution
1366 (H) x 768 (V) at 262K colors
Typical brightness
220 nits
Refresh rate
60 Hz
Viewing angle

Horizontal
40 degrees/40 degrees
Vertical
15 degrees/30 degrees
Pixel pitch
0.250 mm x 0.250 mm\
Display Option 2: High Definition+Wide View Anti-Glare
Maximum resolution
1600 (H) x 900 (V) at 262K colors
Typical brightness
250 nits
Refresh rate
60 Hz
View angle

Horizontal
55 degrees/55 degrees
Vertical
45 degrees/45 degrees
Pixel pitch
0.216 mm x 0.216 mm
Display Option 3: Full High Definition
Maximum resolution
1920 (H) x 1080 (V) at 262K colors
Maximum brightness
300 nits
Refresh rate
60 Hz
Viewing angles
Horizontal
55 degrees/55 degrees
Vertical
45 degrees/45 degrees
Pixel pitch
0.179 mm x 0.179 mm
Keyboard
Number of keys
United States: 83 keys
Europe: 84 keys
Japan: 87 keys
Layout
QWERTY/AZERTY/Kanji
Backlit keyboard
yes
Touchpad
Active area

X-axis
80 mm (3.14 inches)
Y-axis
45 mm (1.77 inches)
Battery
Type
4-cell "smart" lithium ion (37 WHr)
6-cell "smart" lithium ion (60 WHr)
3-year life-time 9-cell"smart"lithiumion(81WHr)
9-cell "smart" lithium ion (90 WHr)
12-cell "smart" lithium ion (88 WHr)
Charge time with computer off
4-, 6-, 9-cell — approximately 1 hour to 80% capacity
and 2 hours to 100% capacity.
12 cell — approximately 3 hours 20 minutes to 100%
capacity.
Operating time
battery operating time varies depending on operating
conditions and can significantly reduce under certain
power-intensive conditions.
Life span
approximately 300 charge/discharge cycles
Dimensions

