Dell Latitude E6510 - Page 48

Depth

4-cell/6-cell
206.00 mm (8.11 inches)
9-cell
208.00 mm (8.18 inches)
12-cell
14.48 mm (0.57 inch)
Height

4-cell/6-cell
19.81 mm (0.78 inch)
9-cell
22.30 mm (0.87 inch)
12-cell
217.17 mm (8.55 inches)
Width

4-cell/6-cell
47.00 mm (1.85 inches)
9-cell
69.00 mm (2.71 inches)
12-cell
322.07 mm (12.68 inches)
Weight

4-cell
237.00 g (0.52 lb)
6-cell
329.00 g (0.72 lb)
9-cell
485.00 g (1.06 lb)
12-cell
848.22 g (1.87 lb)
Voltage
11.10 VDC or 14.8 VDC
Temperature range

Operating
0°Cto35°C(32°Fto95°F)
Storage
–40°Cto65°C(–40°Fto149°F)
Coin-cell battery
3 V CR2032 lithium coin cell
ACAdapter
Input voltage
100 V–240 V~
Input current (maximum)
1.50 A / 2.50 A
Input frequency
50 Hz–60 Hz
Output power
90 W
Output current
5.62 A (maximum at 4-second pulse)
4.62 A (continuous)
Dimensions
Depth
16.00 mm (0.64 inch)
Height
70.10 mm (2.76 inches)
Width
147.00 mm (5.78 inches)
Temperature range

Operating
0°Cto35°C(32°Fto95°F)
Storage
–40°Cto65°C(–40°Fto149°F)
Physical
Depth
253.30 mm (9.97 inches)
Height
28.60 mm (1.13 inches)
Width
374.30 mm (14.73 inches)
Weight
2.51 kg (5.53 lb)
Environmental
Temperature range

Operating
0°Cto35°C(32°Fto95°F)
Non-operating
–40°Cto~65°C(–40°Fto~149°F)
Relative humidity (maximum)

Operating
10 % to 90 % (noncondensing)
Non-operating
5 % to 95 % (noncondensing)
Maximum vibration

Operating
0.66 Grms (2 Hz–600 Hz)
Non-operating
1.30 Grms (2 Hz–600 Hz)

NOTE: Vibration is measured using a random-vibration spectrum that simulates user environment.
Maximum shock

Operating
140 G (2 ms)
Non-operating
160 G (2 ms)

