Dell Latitude XT2 - Page 17





Maximum Resolutions
1280 x 800 at 262 K colors
Operating angle
0°(closed)to160°
Refresh rate
60 Hz (40 Hz in All Day Battery Life (ADBL) mode)
Viewing angles
Horizontal
40/40°
Vertical
15/30°
Pixel pitch
0.204
Power consumption (panel with backlight, typical)
3.0 W (max)
 Keyboard
Number of keys
87 (U.S. and Canada); 88 (Europe); 91 (Japan)
Layout
QWERTY/AZERTY/Kanji
 Touch Pad
X/Y position resolution
(graphics table mode)
240 CPI
Size
Width
73.0-mm (2.9-inch) sensor-active area
Height
42.9-mm (1.7-inch) rectangle
 Battery
Type
4-cell: 28 Whr/14.8V
6-cell: 58 Whr/11.1V
Slice 48: Whr/11.1V
Dimensions:
Depth
4-cell lithium-ion battery
210 mm (8.27 inches)
6-cell lithium-ion battery
210 mm (8.27 inches)
Slice
9.5 mm (0.38 inch)
Height
4-cell lithium-ion battery
18 mm (0.71 inch)
6-cell lithium-ion battery
23.2 mm (0.91 inch)
Slice
186 mm (7.32 inches)
Width
4-cell lithium-ion battery
46.5 mm (1.83 inch)
6-cell lithium-ion battery
68.5 mm (2.7 inches)
Slice
279 mm (10.98 inches)
Weight
4-cell lithium-ion battery
0.2 kg (0.44 lb)
6-cell lithium-ion battery
0.37–0.38 kg (0.82–0.84 lb)
Slice
0.59–0.61 kg (1.3–1.34 lb)
Voltage
11.1 VDC (6-cell, Slice)
14.8 VDC (4-cell)
Charge time (approximate)
Computeroff
approximately 1 hour to 80% capacity (4-cell battery)
Approximately 2 hours to 100% capacity (4 cell battery)
Life span (approximate)
300 charge/discharge cycles
Temperature range
Operating
0°to35°C(32°to95°F)
Storage
-10°to60°C(14°to140°F)
Coin-cell battery
CR-2032
 AC Adapter
Input voltage
90–264 VAC
Input current (maximum)
1.1 A
Input frequency
47–63 Hz
