Dell Latitude XT2 - Page 18





Output current
3.3 A (maximum at 10ms pulse)
2.3 A (continuous)
Output power
45 W or higher
Rated output voltage
19.5 ±1.0 VDC
Dimensions:
Height
16 mm (0.63 inch)
Width
63 mm (2.48 inches)
Depth
88 mm (3.46 inches)
Temperature range:
Operating
0°to40°C(32°to104°F)
Storage
–10°to70°C(–50°to158°F)
 Fingerprint Reader (optional)
Type
UPEKTCS3TouchStrip™stripsensorwithCMOSactive
capacitive pixel-sensing technology
Array size
248 x 2 pixels
 Physical
Height
19.95–26.82 mm (0.79–1.06 inch)
Width
290.6 mm–296.6 mm (11.44–11.68 inches)
Depth
204 mm–226 mm (8.03–8.9 inches)
Weight
1 kg (2.2 lb)
 Environmental
Temperature range:
Operating
0° to35°C(32°to95°F)
Storage
–40° to65°C(–40°to149°F)
Relative humidity (maximum):
Operating
10% to 90% (non-condensing)
Storage
5% to 95% (non-condensing)
Maximum vibration (using a random-vibration spectrum that simulates user environment):
Operating
0.66 GRMS
Storage
1.3 GRMS
Maximum shock (measured with hard drive in head-parked position and a 2-ms half-sine pulse):
Operating
143 G
Storage
163 G
Altitude (maximum):
Operating
–15.2 to 3048 m (–50 to 10,000 ft)
Storage
–15.2 to 3048 m (–50 to 10,000 ft)
Airborne contaminant level
G2 or lower as defined by ANSI/ISA-S71.04-1985
