About Your Monitor | 17
Back View
Back view with monitor stand
Label Description Use
1 VESA mounting holes
(
100 mm x 100 mm -
behind attached VESA
Cover)
Wall mount monitor using VESA-compatible wall
mount kit (100 mm x 100 mm).
2 Regulatory label Lists the regulatory approvals.
3 Stand release button Releases stand from monitor.
4 Security lock slot Supports the use of security lock to prevent theft.
(securi
ty lock not included)
5 Cable cover Offers the protection to the installed cables on the
rear
of the monitor.
6 Barcode serial number
labe
l
Refer to this label if you need to contact Dell for
technical support.
7 Cable clip Use to secure the cables by tightening the screw
on the clip.
8 Cable management slot Use to organize cables by placing them through
the slot.
