About Your Monitor | 19
Monitor Specifications
Flat Panel Specifications
Model MR2217
Screen type Active matrix - TFT LCD
Panel type In-Plane Switching type
Viewable image
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
546.1 mm (21.5 inches)
476.06 mm (18.74 inches)
267.78 mm (10.54 inches)
127479.35 mm
2
(197.59 inch
2
)
Pixel pitch 0.248 mm x 0.248 mm
Viewing angle 178° (vertical) typical
178° (horizontal) typical
Luminance output 250 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
Faceplate coating Anti-Glare with 3H hardness
Backlight LED edgelight system
Response time 14 ms (Gray to Gray)
Color depth 16.7 million colors
Color gamut 72% (typical)*
* MR2217 color gamut (typical) is based on CIE1976 (85%) and CIE1931 (72%) test
st
an
dards.
