Pin Number 4-pin Side of the Connector
1 VCC
2 DMD
3 DPD
4 GND
About Your Monitor | 29
USB Downstream Connector
USB Ports
• 1 upstream - bottom
• 2 downstream - bottom
NOTE: USB 2.0 functionalit
y requires a USB 2.0-capable computer.
NOTE: The moni
tor's USB interface works only when the monitor is On or in the
power save mode. If you turn Off the monitor and then turn it On, the attached
peripherals may take a few seconds to resume normal functionality.
LCD Monitor Quality and Pixel Policy
D
uring the LCD Monitor manufacturing process, it is not uncommon for one or more
pixels to become fixed in an unchanging state which are hard to see and do not
affect the display quality or usability.
